Chunk Filter Provider Model

This page explains how HestiaStore persists chunk filter configuration without persisting runtime objects such as Supplier<ChunkFilter>, secrets, or Spring-managed services.

For filter behavior and ordering see Filters & Integrity. For builder usage and code examples see Filter Configuration.

Core invariants

  • ChunkFilterSpec is the persisted contract. It stores a stable providerId and string parameters.
  • ChunkFilterProvider is a runtime factory. It converts a ChunkFilterSpec into encoding and decoding suppliers.
  • ChunkFilterProviderResolver is runtime configuration used during SegmentIndex.create(...) and SegmentIndex.open(...).
  • ChunkFilterProviderResolverImpl is the immutable map-backed default implementation.
  • ChunkFilterRegistration is builder/runtime glue only. It couples a persisted ChunkFilterSpec with a runtime Supplier<? extends ChunkFilter>.
  • Metadata never stores suppliers, secrets, Spring beans, or provider class names.

Main flow

Chunk filter provider lifecycle

Source: chunk-filter-provider-lifecycle.plantuml

Runtime reopening flow

Chunk filter provider reopen flow

Source: chunk-filter-provider-open.plantuml

Main types

Type Responsibility Persisted
ChunkFilterSpec Stable filter descriptor: providerId + parameters Yes
ChunkFilterRegistration Binds ChunkFilterSpec to a runtime supplier No
ChunkFilterProvider Creates encoding and decoding suppliers for one logical filter family No
ChunkFilterProviderResolver Resolves specs into runtime suppliers No
ChunkFilterProviderResolverImpl Immutable lookup of provider id to provider instance No
ChunkFilterSpecCodec Serializes/deserializes filter specs in manifest.txt Yes

Configure and persist

There are three builder entry points for filter configuration:

  • addEncodingFilter(ChunkFilter) and addDecodingFilter(ChunkFilter)
  • addEncodingFilter(Class<? extends ChunkFilter>) and addDecodingFilter(Class<? extends ChunkFilter>)
  • addEncodingFilter(ChunkFilterSpec) and addDecodingFilter(ChunkFilterSpec)

All three forms end as persisted ChunkFilterSpec entries.

Built-in and legacy class-based filters derive their ChunkFilterSpec automatically through ChunkFilterSpecs. Custom providers supply the ChunkFilterSpec explicitly so metadata can be reopened later.

When IndexConfigurationStore writes metadata, it stores only List<ChunkFilterSpec>. Runtime suppliers are discarded at the persistence boundary.

Reopen and resolve

On reopen, IndexConfigurationStore reads encoded filter specs from manifest.txt, then the index lifecycle asks ChunkFilterProviderResolver to resolve each spec back into an encoding or decoding supplier.

Built-in providers are available through ChunkFilterProviderResolverImpl.defaultResolver(). Custom providers must be added to the resolver configured in IndexConfiguration.filters(...) or passed into SegmentIndex.create(...), SegmentIndex.open(...), or SegmentIndex.tryOpen(...).

This separation is what allows a provider to depend on runtime services such as Spring beans, a key resolver, or a KMS client while still keeping persisted metadata stable.

Metadata format

ChunkFilterSpecCodec stores one pipeline item as:

p=<providerId>|<key>=<value>|<key>=<value>

Example:

encodingChunkFilters=p=crc32,p=magic-number,p=snappy,p=aes-gcm|keyRef=orders-main
decodingChunkFilters=p=magic-number,p=aes-gcm|keyRef=orders-main,p=snappy,p=crc32

Legacy metadata containing only a class name is still supported and is mapped to the built-in java-class provider.

The aes-gcm provider id in the example above is a custom provider id, not a built-in default. A typical implementation materializes ChunkFilterAesGcmEncrypt and ChunkFilterAesGcmDecrypt using a runtime key resolver and the persisted keyRef parameter.

Materialization and performance

Providers return Supplier<? extends ChunkFilter>, not chunk filter instances. This keeps provider resolution out of the hot per-chunk path.

Supplier materialization happens when HestiaStore creates the chunk I/O runtime for a reader or writer, where ChunkStoreReaderImpl and ChunkStoreWriterImpl materialize a fresh filter list before building ChunkProcessor.

That means:

  • providers can return stateful filters
  • secrets can stay outside persisted metadata
  • per-chunk processing still works with concrete filter instances only

Built-in providers

The default resolver ships with these provider ids:

  • crc32
  • magic-number
  • snappy
  • xor
  • do-nothing
  • java-class

Each provider id represents one logical encode/decode pair. For example, snappy means ChunkFilterSnappyCompress on write and ChunkFilterSnappyDecompress on read.

Provider ids outside that list, such as aes-gcm, must be supplied by the application through an extended ChunkFilterProviderResolver.
